Leather Splitting Machine working width 300 mm.

Technical Data
Maximum cutting thickness mm 8.
Minimum cutting thickness mm 0.1 with the bar – mm 0.5 with the roller.
Control panel with digital thickness indicator. Multipurpose sharpening
device for grindstones in ceramic or borazon. Sharpening device pressure
adjustable with micrometric drive. Feed speeds: 3 manual 7-11-16 mt./min.
Knife tension indicator. Quick change upper roller/guide bar. Self adjusting
knife guide plate. Micrometric adjustment of lower roller pressure. Idle Upper
roller. Lower feeding roller made of special steel. High precision long-life guides.
Optical device to control the chamfer position and symmetry. Wastes exhauster.
Absorbed power max. 2 kW
Power supply three-phase 400V 50/60 Hz

Optionals
Borazon Grindstones
Upper feeding roller
Rubber Lower roller
Pre-Opening device with table stop
Special customized toolings to skive Belts and Stripes

Machine dimensions cm. 125 x 100 x 113 h.
Machine weight Kg 350

Technical features are indicative and non-binding
